TP250TV Vertical Cantilever Pump, Warman 250TV-SP ...

Tobee® TP250TV Vertical Cantilever Pump is centrifugal sump slurry pumps submerged in sump to work.It is designed for delivering abrasive, large particle and high density slurries. The pumps have no need of any shaft seal and sealing water. it can also be operated normally for insufficient suction duties. The submerged depth can be customed as different sump.

View Details

Design Features:

• Bearing Assembly - The bearings, shaft and housing are generously proportioned to avoid problems associated with the operation of cantilevered shafts in the first critical speed zones.
The assembly is grease lubricated and sealed by labyrinths; the upper is grease purged and the lower protected by a special flinger. The upper or drive end bearing is a parallel roller type whilst the lower bearing is a double taper roller with preset end float. This high performance bearing arrangement and robust shaft eliminates the need for a lower submerged bearing.
• Column Assembly - Completely fabricated from mild steel. The TPR model is elastomer covered.
• Casing - Has a simple bolt-on attachment to the base of the column. It is manufactured from a wear resistant alloy for the SP and from moulded elastomer for the TPR.
• Impeller - Double suction impellers (top and bottom entry) induce low axial bearing loads and have heavy deep vanes for maximum wear resistance and for handling large solids. Wear resistant alloys, polyurethane and moulded elastomer impellers are interchangeable. The impeller is adjusted axially within the casting during assembly by external shims under the bearing housing feet. No further adjustment is necessary.
• Upper Strainer - Drop-in metal mesh, snap-on elastomer or polyurethane for TP and TPR pumps. Strainers fit in column openings.
• Lower Strainer - Bolted metal or polyurethane for TP, moulded snap-on elastomer for TPR.
• Discharge Pipe - Metal for TP, elastomer covered for TPR. All wetted metal parts are completely rust protected.
• Submerged Bearings - None
• Agitation - An external agitator spray connection arrangement can be fitted to the pump as an option. Alternatively, a mechanical agitator is fitted to an extended shaft protruding from the impeller eye.
• Materials - Pumps can be manufactured in abrasive and corrosive resistant materials.

Tobee® TP250TV Vertical Cantilever Pump Performance Parameter:

Power P

(kw)

Capacity Q

(m3/h)

Head H

(m)

Speed n

(r/min)

Eff. η

(%)

Impeller dia.

(mm)

Max. particles

(mm)

Weight

(kg)

TP(R)250TV

250TV-SP(R)

18.5-200

261-1089

7-33.5

400-750

60

575

65

3700

Tobee® TP250TV Vertical Cantilever Pump Structural Drawing:

Metal Lined Vertical Slurry Pump

Rubber Lined Vertical Slurry Pump

No

Parts name

Materials

No

Parts name

Materials

1

Shaft

4140 High Tensile Steel*

1

Shaft

4140 High Tensile Steel*

2

Bearing

SKF/Timken (Standard)

2

Bearing

SKF/Timken (Standard)

3

Bearing Housing

HT250

3

Bearing Housing

HT250

4

Bearing spacer

420 Stainless Steel

4

Bearing spacer

420 Stainless Steel

5

Bearing

SKF/Timken (Standard)

5

Bearing

SKF/Timken (Standard)

6

Shim

20# Stainless steel

6

Shim

If you are looking for more details, kindly visit SUNBO PUMP.

20# Stainless steel

7

Column

20# Stainless steel

7

Column

20# Stainless steel

8

Strainer

QT500-7

8

Strainer

Natural rubber

9

Back liner

27.5% UltraChrome Alloy

9

Back liner

Natural rubber

10

Impeller

27.5% UltraChrome Alloy

10

Impeller

Natural rubber

11

Pump casing

27.5% UltraChrome Alloy

11

Pump casing

Natural rubber

12

Lower strainer

QT500-7

12

Lower strainer

Natural rubber

13

Discharge pipe

20# Stainless steel

13

Discharge pipe

20# Stainless steel

14

Flushing pipe

Q235 Carbon steel

14

Flushing pipe

Q235 Carbon steel

15

Coupling

45# Steel

15

Coupling

45# Steel

16

Middle supporting parts

20# Stainless steel

16

Middle supporting parts

20# Stainless steel

Tobee® TP250TV Vertical Cantilever Pump Component Design:

Tobee® TP250TV Vertical Cantilever Pump After-sales Service:

As the slurry pump wet ends parts such as the impeller, volute liner, FPL insert, Throat bush, shaft sleeve are consumption parts and we could provide you always the qualified slurry pump parts within very short time.

Packing Transport Services
Considering the order pump size and we could provide case or pallet as per your need to make sure it safe enough during the long distance road and ocean shipping. having own export company and so we could help you find the best ocean shipping solution and service for you from the goods out of factory to your destination.

Installation Services
Tobee Pump have more than 30 years experienced pump installation workers and are very aware of any onside application. We could provide abroad pump installation service and expect pump manufacturing and sales,abroad pump installation is getting more and more popular by our regular clients abroad.

Technical Support Services
Technical data sheet, Performance curve, General arrangement drawing, Operating manual will be sent within 24th for your checking, So Pls feel free to contact us If you have any need.

Tobee® TP250TV Vertical Cantilever Pump On-site Applications:

• Mining
• Mineral processing
• Construction
• Chemical and Fertilization
• Power generation

• Phosphate matrix fertilization
• Paper mill wastes and liquors
• Precipitated CaCO3
• Plaster
• Bottom/fly ash, lime grinding

• Pulp and paper
• Oil and gas
• Waste water treatment
• Dirty water
• Waste sludge

• Ball mill discharge
• Rod mill discharge
• SAG mill discharge
• Fine tailings
• Flotation
• Heavy media process
• Minerals concentrate
• Mineral sands

• Coal-washing plant
• Coarse sand
• Coarse tailings
• Dredging
• FGD
• Wet crushers aplications
• Wet scrubber systems
• Process chemical

• Iron and Steel
• Ni acid slurry
• Fracking slurries
• Clay and sand slurries
• Kaolin clay
• Carbon slurry
• Lime mud
• Oil sands
• Phosphoric acid
