Optical mirror : a complete guide

&#;Magic mirror, on the wall &#; who is the fairest one of all?&#;.

If you are looking for more details, kindly visit our website.

While this guide won&#;t provide answer to the Queen&#;s request in Disney Classic, Snow White and the seven Dwarfs, you&#;ll get a glimpse of the optical mirrors offer you can find on the market and select the best mirror that may fit your needs.

Optical mirror definition

An optical mirror is a precision optics component made of a optical polished substrate material and a high reflection coating. It can be of various shape and dimensions from less than a millimetre to several meters.

Optical mirrors are found in all the Photonics applications : in astronomy inside every telescope, in lasers by design, in vision equipment, and most of the optical assemblies systems. While their usage is quite simple : reflect the light, their range of application is wide, from UV to IR it can be used to transmit light with a change of direction, to focus light (for example in a Cassegrain telescope) or pumping light in a laser.

Types of optical mirrors

Shapes

Under the name &#;mirror&#; are many different types of precision optics that may be sorted as one of below type :

• Flat mirror, it is the simplest form similar to bathroon mirrors with higher precision.
• Spherical mirror, relates to mirrors with a radius of curvature either concave or convex.
• Aspherical mirror, more complex shape mirrors designed to attenuate optical aberration of reflected beam. For example : off-axis parabolic mirrors which are used to collimate a bean à 90° angle.
• Elliptical mirrors, are usually used at a 45° angle where they provide optimum circular clear aperture.
• Concave mirrors, the concave shape increase the reflection that can go more than 99% with an angle of incidence (AOI) of 0°.
• Freeform mirrors
• Prism mirrors, can be used either with outside reflection or inside reflection.

 Substrate material

Mirrors substrate material are usually selected for their good shape resistance to temperatures changes, easiness of coating to bound with it and easiness of polishing to guaranty a good polishing shape. For some high power laser applications, substrate can also be the in LIDT constraint and therefore be selected carefully.

Below table shows most common substrate material for mirror blanks :

Substrate material Remarks Float Very cheap material that comes with acceptable polishing and flatness level for low requirement applications. Fused silica Resistant material with good optical machining properties, very commonly used. N-BK7 / H-K9L Most common optical glass, can be used for high requirement surface aspects. Zerodur Material almost non affected by low temperature, used mainly for space applications. Metals Polished aluminium or brass can be used for some high power laser applications, they are also easier to machined than glass type material and mechanicaly stronger. Plastics Plastic substrates are used in optical applications, but the difficulty to keep a good surface quality and the easy wearing of the parts due to outside environment limit its usage, while this remain the cheapest substrate material.

Remark : for some applications where mirrors maybe of important dimensions and the part weight is an important constraint like in space industry for example, a lightening of the part can be done with a structuring of the back of the substrate.

Mirror coating

The most important part of an optical mirror is its high reflection coating, it is that coating that will be at the interface of incident beam and reflect it to an orthogonal direction.

Broadband dielectric coatings

With the improvement of vacuum deposition equipment in the last 30 years, layer of dielectric material can be deposit of substrates with a nanometric precision.

The material and the thickness used for each layer enable the trimming of  a broadband of wavelengths where the incident beam will be reflected.

It has to be noted that the reflection of such mirror degrades as the AOI increases.

Metal-coated mirrors

Coating metal RefLection Indicative damage threshold Remarks Protected* silver Ravg>97.5% on the visible + NIR, Ravg>96% on MIR+FIR 3J/cm2 Very good reflection in the visible Protected* Aluminium Ravg>90% on the visible + NIR, Ravg>95% on MIR+FIR 0,3J/cm2 A MgF2 layer can be added to improve reflection in the UV (250 to 400nm) Protected* Gold Ravg>96% on the IR 2J/cm2 Without surprise the most expensive of the metal coatings.

*Metal coatings are protected with SiO2 layers in order to avoid corrosion.

**An additional Chromium layer is usually added between the substrate and the metal to improve adhesion.

Laser mirrors

The critical specification for optical mirrors to be used in laser applications is their LIDT (Laser Induced Damage Threshold, or in short Damage Threshold).

This specification often measure in J/cm2 defines the energy that can be accepted by a surface area.  (for reminder Watts are defining a power so values in Watts should be integrated in the time to be translated to energy).

LIDT should be defined with detail of the type of reference laser : CW or pulse laser, pulse duration, frequency and power.

Usually the coating is the contraint before the substrate, but for high power laser substrate can be wear by laser usage too. The lower the polishing  and the higher of impurities in the material will bring to lower LIDT of the substrates.

Deformable mirrors

Deformable mirrors are active optics elements used in adaptative optics. They are typically made of an optical membrane, actuators and an electronic controller.

Their main usage is compensating aberrations, from example of the atmosphère in astronomy, of the eye in ophthalmology or of the cells water in biomicroscopy.

Main suppliers of deformable mirrors are ALPAO and ISP-System for high power applications.

Hot mirrors and cold mirrors

What are Hot mirrors and cold mirrors ? It is rather intuitive (while sometimes confusing) :

• Hot mirrors are reflecting the IR part of an incident beam and transmit the visible part of it.
• Cold mirrors are transmitting the IR part of an incident beam and reflect the visible part of it.

In a nutshell : Hot mirrors reflect warmth, cold mirrors reflect cold signal.

They are used to separate visible to IR parts of an optical signal.

Where to buy optical mirrors ?

Like most optical components optical mirrors are bought from precision optics manufacturers & distributors. It is rather common that the substrate and the coating are made in two different site, therefore buying mirror blank and doing the coating in-house or subcontracting it to other supplier is common practice.

Don&#;t hesitate to contact SINOPTIX for your questions about optical mirrors or to request for a quote.

Mirror lenses, which are also known as &#;catdiotropic&#; or &#;reflective,&#; were all the rage in the &#;70&#;s, and 80&#;s but dropped out of favour in the &#;90&#;s . In the digital age do they have a purpose? This article tests several mirror lenses from different manufacturers, explains the advantages and disadvantages compared to conventional (refractive) lenses and shows how most of the disadvantages can be overcome in the digital darkroom. There are plenty of test pictures throughout and sample images taken in the years since I carried out the test all available in a Flickr album at up to full size.
Up until around 6 years ago, Tamron, Nikon, Zeiss and Minolta all still had mirror lenses in production. Now of the big brands only Sony have one available, and this is the previous Minolta model rebranded. There are some other cheaper makes such as Kenko, Vivitar and Centon new. There are plenty of lenses to choose from on ebay, and I bought 4 of them to evaluate, eventually selling all but one.

For some reason I really like the retro graphics on the Tamron lenses!

Why a mirror lens?
Mirror lenses are telephoto lenses that use a combination of two mirrors to reflect light back and forth between the ends of the lens prior to the light passing through to the camera. (See diagram) This means that the physical size of the lens is around a third of the size of a conventional lens and the mirrors are also much lighter than the optical glass.

The small physical size and weight of the Mirror lens means that it is possible to hand hold with an appropriately fast shutter speed and of course the lens does not look like a paparazzi tool, so it is discrete. It is also far more likely that you&#;ll be carrying a mirror lens, it is unlikely that you&#;ll pack a 500mm F4 refractive lens for a walk about town! Chromatic aberration is virtually absent by design.
Mirrors are significantly cheaper than conventional long telephotos, starting at around £100 for a cheap brand up to £ for the best manufacturers, with the better independents available second hand on ebay for £150.
Mirror lenses have no mechanical or electronic link with the camera body as their is no variable iris, so it is possible to fit almost any mirror to almost any SLR with an appropriate adaptor. For my Canon 5D, I was able to obtain adaptors for Contax/Zeiss, Nikon, Pentax K and Tamron.

The disadvantages
It was all sounding too good to be true &#; so here is a list of the disadvantages.
The aperture and focal length is fixed &#; the most common versions are 500mm f8, 350mm 5.6.
The fixed aperture means there is no control over depth of field. At these focal lengths and apertures, the depth of field is very small, making these images most suitable for objects that are at the same distance. For example the side of a building face on is fine, but shooting that same building at an angle will result in a visible plane of focus with everything else in front and behind blurred. Unfortunately the out of focus parts of the image (bokeh) can look messy and distracting with out of focus highlights turning into rings of light &#; or doughnuts &#; a mirror lens characteristic which can be attractive when used appropriately.

The images from all these lenses tend to have bright centre with dark corners &#; Vignetting, or even a marked &#;hotspot&#; in the centre. The Nikon was the worst, however easy to fix using the vignette tool in Lightroom, I used +55 midpoint 12 to fix the Nikon.

All the mirror lenses apart from the Sony (Minolta) 500mm f8 are manual focus and it can be tricky to focus a 500mm f8 as the viewfinder is quite dark.  The Sony AF Mirror is very light and takes advantage of the in-camera Image Stabilisation, making it possible to handhold, even on a crop sensor body like the A700 &#; in this case giving 750mm effective focal length. The autofocus certainly makes life easier, although it does have a tendency to &#;hunt&#; which given the small aperture (f8) is not surprising.

Exposure problems. In the days of film these problems lead to the downfall of the &#;Cat&#; lenses. The fixed aperture and of course fixed ISO for a particular roll of film meant that shutter speed was the only variable, albeit a very inconvenient neutral density filter (fitted to the back of the lens) could reduce the amount of light. The shutter speed needed to be fast (above 1/500th second) to avoid camera shake, so the conditions in which a successful shot would result were limited.

How digital can mitigate these faults (to a degree)
The combination of shooting digitally and simple corrections in software like Lightroom in post processing enables some of these disadvantages to be overcome, to a degree where it is once again worth thinking about adding one to your collection.
Exposure &#; with a digital SLR the ISO is variable, so the photographer can use ISO to ensure a fast enough shutter speed.
Vignetting is easy to remove &#; as long as RAW images are used, the RAW converters have a simple slider to remove this- better still this is consistent from one picture to another, so once the position of the slider is determined all the other images can be corrected in seconds. (Doing this to JPEGS will significantly degrade image quality as there is so little data in the shadows, that there will be a considerable increase in noise)
Manual focus is probably the biggest disadvantage to overcome as the depth of field for a 500mm lens at f8 is very small &#; and of course smaller with subjects that are physically closer.

Modern autofocus SLR&#;s also don&#;t help you to manual focus as there is no aid on the focussing screen. There are two ways around this. For owners of expensive DSLR&#;s eg Canon 1 series, the centre focus point will light up when the image is in focus, so the photographer can turn the focus ring until the light comes on and be assured of sharp focus. Sony Alpha users can choose the autofocus 500mm f8. For the rest of us we just have to be really careful with manually focussing, I often bracket focus, taking several shots with slightly different settings hoping that one will be right. Modern DSLR&#;s with live view can be used to aid focussing, simply zoom in electronically to precisely focus. This has proved successful when using the mirror lenses on the Canon 5dmk2. However this is quite time consuming and certainly not of use for fast moving objects.
Bokeh is also a tricky issue. It becomes more critical with a mirror lens to choose a plain background for the subject. When this is not possible &#; digital manipulation could be needed to edit anything particularly distracting.

In summary for the digital photographer it is a balance between,





For Light weight and physical size, discrete, cheap Against Manual focus, small depth of field poor bokeh, slow to use

The lenses Tested at a glance.
All the lenses were tested using a Canon 5D full frame DSLR &#; at the time one of the hardest tests for any lens. The 5D suffers from vignetting so the Mirror lenses would exaggerate this. Subsequently I have taken some shots with my 5D mk2, but only with the lens I kept. Note that it is quite straightforward to fit any of these lenses to a Canon EOS full frame as they do not have variable aperture, and thus require no electronic communication to the body. It is therefore just a physical fit required. Some enterprising folks o nubby have realised how hard these lenses are to focus manually so are creating &#;Focus Confirm Adaptors&#; &#; These have contacts and a programmable chip built in that enable the focus confirm lights in the 5D range to illuminate when the image is in focus.  I have now also tested the Zeiss with the Canon 5Dk3 using a Focus Confirm adaptor.

Manufacturer Length Aperture Price new Price USED Adaptor Nikon 500mm f8 £ £200 £15 Tamron 500mm f8 £400 £150 £30 Carl Zeiss / Contax 500mm f8 £ £ £25 Tamron 350mm f5.6 £300 £170 £30

Nikon 500mm F8.

This was the third and final version of the Nikon 500mm f8., identified by it&#;s orange stripe, it focuses more closely than the older versions. Introduced in its predecessor was in production for 25+ years.

Build quality is very high, smooth focussing mechanism, solid case and integrated tripod bush. The built in non-adjustable hood is perhaps to short, while adding to the physical size of the lens. This came with a fake leather case with space for filters underneath the lid. This really felt like a high quality expensive product.

Slideshow of sample images from the Nikon

This slideshow requires JavaScript.

Tamron 500mm f8
This cult product was one of the best selling mirrors and with good reason. There were a number of different &#;Adaptal 2&#; lens mounts to choose from making it possible to fit it to most SLR&#;s. The build is good &#; though it doesn&#;t feel as robust as the Nikon. The silver evaporated mirrors were much heralded at the time. The lens hood is separate and must be screwed in. When not in use it can be reversed and placed over the body of he lens but doesn&#;t stay attached which is annoying. There was a matching 2x teleconverter made by Tamron, &#; this wasn&#;t tested. There is no integrated tripod bush &#; indeed it is not possible to fit the lens on a tripod at all. Instead Tamron provide a circular extender plate to screw onto the camera body. This has a tripod bush underneath and enables the camera to be fitted to the tripod with the lens attached &#; the lens would be too fat without it. The lens is so small and light that I didn&#;t feel this was a disadvantage, however it lacks the ability to turn the camera between portrait and landscape on the tripod ring in the way that all the other lenses here can do. The Tamron came with an attractive oblong fake leather case, with space inside for tripod bush and filters.
n.b. Due to a copyright infringement lawsuit brought by Canon, Tamron had to stop production of the EOS mount for the Adaptal and SP ranges of lenses, so an EOS Canon mount became as rare as hens teeth until some enterprising Chinese manufacturers starting making mounts and selling them via ebay.

Sample Images Tamron 500mm f8

This slideshow requires JavaScript.

Tamron 350mm f5.6.
This rare lens was well regarded at the time, it&#;s focal length makes it particularly of use for SLR&#;s with an APS-C sized sensor, giving an effective 525mm on Nikon, or 560mm on a Canon. Unlike the Tamron 500mm, this lens has an integrated tripod bush that allows easy movement from portrait to landscape. The screw on hood reverses over the lens for storage, but again is loose.

This slideshow requires JavaScript.

Featured content:
How Does Electric Vehicle Battery Production Work?
The Advantages of Utilizing a Telecommunications Signal Generator
How to Choose a Signal Generator for Research and Development?
How Power Quality Analyzers Improve Hospital Reliability?
Key Questions to Ask When Choosing a Spectrum Analyzer for RF Measurement
Mastering Telecommunications Signal Generator Manufacturing Techniques
4 Tips for Selecting the Right High-Purity Signal Generator Dealer

Link to yanggu

Contax Zeiss Mirotar 500 f8.
This lens is only available in Contax / Yashica mount, but adaptors are readily available on ebay for most cameras. Zeiss have a great deal of experience making mirror lenses for telescopes. This is quite a rare lens, unlikely to find this on ebay, but still available new in the UK from ffordes in Scotland, who bought up all the stocks from Contax when they stopped production. This is the &#;Rolls Royce&#; of the mirror lenses here, beautifully made with smooth focus action and precision fitting sliding lens hood and revolving tripod bush.

Other lenses

Centon 500mm f8 approx £100 plus T2 mount

I bought one of these new from Jessops a few years ago, and shot a whole roll of film, with Canon A1 on a tripod, I was really careful with focussing, using bracketing etc. I didn&#;t get one single sharp image, so I returned it for a refund. This lens is just a piece of junk!

The Sigma 600mm.

There appears to have been two versions of this, the standard black one and a green one. I tried the black version in a shop in Bath, I took a few pictures with it. The images were of extremely low contrast and quality. I decided not to part with the £150 for this. Tests at the time by Amateur photographer were not complimentary about this lens either &#; it was consistently outperformed by the Tamron 500mm, regarded as the best independent of its day. I have subsequently bought one and found that it is capable of good results on the 5D mk3. While I didn&#;t include it in this comparison (as I didn&#;t own it at the same time as the others here) I will upload some results and test it separately.

The photographic tests

I found suitable locations and used a tripod, switching lenses and noting on paper the shots that corresponded to each lens. Note that these lenses have no electrical connection, so no aperture date or distance is provided to the camera. As focusing is so tricky with these lenses I took several images, bracketing focus and have chosen the best example from each lens.

Image1. House on the hill.

Image 2. Buildings on Brighton seafront click for 100% Crops

These images were taken from Hove Lawns, with a tripod. I shot several of each with different focus points. I focussed on the white steps. The Carl Zeiss is clearly sharpest, followed by the Tamron and Nikon.

Walkabout images.

A few observations and tips for getting the best results
I went out on numerous occasions and used each of the lenses to see what sort of images I could get. The lens is inconspicuous, so you don&#;t get the sort of attention that you would with a paparazzi lens. Distance subjects work better than close ups. The Tamron 500m is the best at close ups, but the usefulness of this is reduced by the universally achieved poor background blur, so careful selection of backgrounds is essential. Nearly out of focus areas look distracting. These lenses work much better with objects that are at the same focus distance with nothing in the foreground or background.

Taking people pictures.

I managed to get some good images of people, including managing to get the out of focus doughnut highlights, which I rather liked in this context. In the 70&#;s magazines often had portraits shot against the sun on sea to achieve this effect.
The tiny depth of field helps &#; if the people are standing up, but I found that the limited depth of field means that their face could be in focus, but other parts of the body blurred.

Action
Moving objects are trickier, requiring pre-planning of where the moving object is travelling to and focussing in advance. This technique was used for the skateboarder, I focused on a cone ahead of the subject and waited for him to move into the plane of focus.Trying to focus and pan at the same time is very difficult.
Action pics

Overall ratings

Lens Handling Sharpness Vignetting Build Value Total Nikon 4 3 1 5 2 15 Tamron 500
2 4 2 3 5 16 Carl Zeiss / Contax 5 5 4 5 4 23 Tamron 350
3 1 2 3 2 11

Handling

The smooth focussing action, integrated hood, and excellent tripod bush win this for the Zeiss. The Tamron 350 gets the nod over the 500mm because of the integrated tripod bush.

Image quality &#; Sharpness and Vignetting.

The Zeiss has the least vignetting effect, has the best contrast and is the sharpest. The Tamron better than any of the others closeup. The Nikon has a characteristic central hotspot, and is no sharper than the Tamron 500mm.

The Tamrons 350 is soft and suffers especially from low contrast and vignetting, I really struggled to obtain a sharp image from this optic.

Value for money

My Favourite without doubt is the Contax Zeiss Mirotar, the best handing, build and image quality, (and the one I decided to keep).  I would certainly have not have paid £ for one as a modern Canon L or high end Sigma for that price would be more versatile (but bigger) at £ used however, and subsequently testing it on the 5D mk3 with focus confirm adaptor &#; it is the lens to buy now as it&#;s improved sharpness over the other lenses here mean that it better makes use of the higher resolution modern cameras.  The Tamron 500mm was available for £400, it is closer in image quality than you might expect (on the 12MP 5D) and is the overall Best Buy in this test &#; unless you have a 20MP+ camera). Now available for under £200 used with mounts that fit a whole range of DSLR&#;s this is the lens to look for to see how it is &#;all done with mirrors&#;. The Nikon is poor considering it cost £ new. The build quality is high but the image quality didn&#;t match up. The Tamron 350mm is rare and thus expensive, frankly I wouldn&#;t bother with it, it was the first one I sold, and it is easy to get to 350mm with a conventional lens.  Close up images 20 feet away! were especially soft.

Overall
The Mirror lens is not a replacement for a high end 500mm lens like those from Nikon or Canon, but you are much more likely to find yourself out and about with one. These refractive lenses cost thousands of pounds and weigh several Kilos. The mirror lens gives you a low cost route to large magnification, as powerful as a pair of 10×50 binoculars they will give you a different perspective, and maybe some interesting images, but overall I found them fun to use. When buying second hand, be sure to look into the lens and check that there is no mould growing in the mirrors. All the lenses I tested were flawless.

My recommendation is to find a low cost Tamron 500m f8 for around £150-200 and have some fun, or if you can afford it £ for the Zeiss will get you the best 500mm mirror lens ever made! If you are a Sony Alpha user, you can buy the only autofocus mirror lens available, though I have taken some pictures with it  and from my short experience with it I&#;d say it is certainly worth a try.

You have probably guessed, I kept the Zeiss, see examples that I have taken with it here.

Now see PART 2 of this test &#; updatedin

https://atomic-temporary-.wpcomstaging.com/mirror-mirror-a-guide-to-choosing-and-using-mirror-lenses-part-two/



Notes and links

Zeiss Mirotar 500mm on Canon EOS 5D mk3 with Focus confirm adaptor.

The 500mm f8 Reflex Group on Flickr &#; some great shots!

The Reflex lens Group on Flickr

The development history of the Nikon 500mm lens is really quite interesting and can be seen here.

Zeiss have a technical paper on the design of the Mirotar.

Bob Atkins has compared the Tamron 500mm 8 to a Canon 500 f4.5 &#; it makes interesting reading.

Test of the Sony 500mm f8 with Autofocus.

Minolta/Sony Mirror lens used for wildlife images

Zeiss Mirotar on Flickr
