PC strand

PC Strand, or prestressed concrete steel strand, is a twisted steel cable composed of 2, 3, 7 or 19 high strength steel wires and is stress-relieved (stabilized) for prestressed concrete or similar purposes.

Are you interested in learning more about indented prestressed steel wire? Contact us today to secure an expert consultation!

Classification

[

edit

]

PC strand is classified according to the number of steel wires in a strand: 2 wire strand, 3 wire strand, 7 wire steel strand[1] and 19 wire steel strand. It can be classified according to the surface morphology and can be divided into: smooth steel strand, scoring strand, mold pulling strand (compact), coated epoxy resin steel strand. They can also be classified by diameter, or intensity level, or standard.

Specifications

[

edit

]

In the description and list of the table we often see, there are 15-7Φ5, 12-7Φ5, 9-7Φ5 and other specifications of the prestressed steel strand. To 15-7Φ5, for example, 5 said a single diameter 5.0mm of steel, 7Φ5 said seven of the steel wire to form a strand, and 15 that the diameter of each strand of 15mm, the total meaning is "one The beam consists of 7 strands of diameter 15 mm (each having a total diameter of about 15.24 mm, a dimensional deviation +0.40 -0.20; a diameter of about 5.0 mm per filament). The general sectional area is calculated according to 140mm ^ 2. The theoretical breaking value is 140 * = 260.4 kN, which can withstand the tension of 156.24-169.26 kN according to the prestressing standard of 60% -65%.

Materials

[

edit

]

Using high-carbon steel wire rod, after surface treatment it is cold drawn into steel wire, and then the strand structure will be a number of steel wires stranded into shares. Next the elimination of stress by way of a stabilization process. In order to extend durability, the wire can have metal or non-metallic coatings, such as galvanized, or epoxy resin coating. In order to increase the bond strength with the concrete, the surface can have nicks and so on. The prestressed strands of the mold are twisted to form a mold compression process, the structure is more compact, and the surface layer is more suitable for anchoring. Production of unbonded prestressed steel strand (unbonded steel strand) using ordinary prestressed steel wire, coated with oil or paraffin after the packaging into high-density polyethylene (HDPE) bags.

Features

[

edit

]

The main characteristic of the prestressed steel strand is high strength and relaxation performance is good, the other when the more straight. Common tensile strength levels of MPa, as well as , , , , MPa and the like intensity levels. The yield strength of this steel is also higher.

Application

[

edit

PC strand

PC Strand, or prestressed concrete steel strand, is a twisted steel cable composed of 2, 3, 7 or 19 high strength steel wires and is stress-relieved (stabilized) for prestressed concrete or similar purposes.

Classification

[

edit

]

PC strand is classified according to the number of steel wires in a strand: 2 wire strand, 3 wire strand, 7 wire steel strand[1] and 19 wire steel strand. It can be classified according to the surface morphology and can be divided into: smooth steel strand, scoring strand, mold pulling strand (compact), coated epoxy resin steel strand. They can also be classified by diameter, or intensity level, or standard.

Specifications

[

edit

]

In the description and list of the table we often see, there are 15-7Φ5, 12-7Φ5, 9-7Φ5 and other specifications of the prestressed steel strand. To 15-7Φ5, for example, 5 said a single diameter 5.0mm of steel, 7Φ5 said seven of the steel wire to form a strand, and 15 that the diameter of each strand of 15mm, the total meaning is "one The beam consists of 7 strands of diameter 15 mm (each having a total diameter of about 15.24 mm, a dimensional deviation +0.40 -0.20; a diameter of about 5.0 mm per filament). The general sectional area is calculated according to 140mm ^ 2. The theoretical breaking value is 140 * = 260.4 kN, which can withstand the tension of 156.24-169.26 kN according to the prestressing standard of 60% -65%.

Materials

[

edit

]

Using high-carbon steel wire rod, after surface treatment it is cold drawn into steel wire, and then the strand structure will be a number of steel wires stranded into shares. Next the elimination of stress by way of a stabilization process. In order to extend durability, the wire can have metal or non-metallic coatings, such as galvanized, or epoxy resin coating. In order to increase the bond strength with the concrete, the surface can have nicks and so on. The prestressed strands of the mold are twisted to form a mold compression process, the structure is more compact, and the surface layer is more suitable for anchoring. Production of unbonded prestressed steel strand (unbonded steel strand) using ordinary prestressed steel wire, coated with oil or paraffin after the packaging into high-density polyethylene (HDPE) bags.

Features

[

edit

]

The main characteristic of the prestressed steel strand is high strength and relaxation performance is good, the other when the more straight. Common tensile strength levels of MPa, as well as , , , , MPa and the like intensity levels. The yield strength of this steel is also higher.

Application

[

edit

Featured content:
Woven Wire Mesh vs. Perforated Metal
4 Tips to Select the Best Matte Prepainted Steel Coil Price
How to Select Transverse Reinforcing Mesh Panel?
What are the benefits of using geogrid in road construction?
Quelles sont les défaillances des câbles en acier ?
Wie wähle ich einen Spanngurt mit Ratsche aus?
Wie verwendet man Ratschenzurrgurte?

]

In most of the post-tensioned and pre-tensioned prestressed project, smooth steel strand is the most widely used prestressed steel. Stranded strand is mainly used to enhance the project, but also for nuclear power and the like works. Galvanized steel strand commonly used in the bridge of the tie rod, cable and external prestressing works. Epoxy coated steel stranded wire is similar to galvanized prestressed steel wire.

Standards

[

edit

]

Countries have standards for prestressed strand, such as: China Standard GB / T , American Standard ASTM A416, British standard BS and the Japanese standard JIS G, the Australian standard AS / NZS , Brazilian standard NBR-[2]

References

[

edit

]

Prestressing and Post Tensioning PC Strand - PC Wire

Prestressed Concrete Steel StrandPrestressed Concrete Steel Strand ( simplied as PC strand ) is a multi-wire steel cable helically wound by 2, 3, 7 or 19 high-strength steel mono wires. PC steel strand is widely used in slab post-tensioning, pre-stressing, mining, and stay cable applications.
We supply:
2 wire pc strand;
3 wire pc strand;
7 wire pc strand ( most popularly used);
19 wire pc strand.
We supply following Quality of Steel Strands for PC Concrete:
GB/T:1×7-9.5mm/11.1mm/12.7mm/15.2mm/15.7mm/17.8mm/21.6mm
ASTM416:1×7-7.9mm/9.53mm/11.11mm/12.7mm/13.2mm/14.29mm/15.24mm/17.8mm
BS :1×7-8.0mm/9.3mm/9.6mm/11.0mm/12.5mm/12.9mm/15.2mm/15.7mm
JIS G:1×7-12.7mm/15.2mm
UNE :1×7-9.3mm/13.0mm/15.2mm
AS/NZS: 9.5mm(7 wire)/12.7nn/15.2mm
Specifications can be customised according to customers / projects requirements.
How is Prestressing Strand Used:
Prestressing strand is fabricated into tentons, cages and guide channels (ducts) by strand pushing machine to be used in concrete constructions.

PRESTRESSED CONCRETE STRAND PRODUCTS

- EXPORT COUNTRIES AND QUALITIES

12.54 mm (0.6inch) prestressed concrete pc stranded wire for the tendons, supplied with anchors

PC Strand, low relaxation, left hand lay, plain.
Specification: ASTM A416-06
Size: 0.6"(15.24mm)
T/S: Mpa(min.)
Coil weight: 2.3MT(Min.)
Packing: 2 layers of water resistant materials and wrapped around each coil, 2 wooden dunnages underneath each coil.
Wire strand exported to Korea

Prestressed Concrete Strand (used in construction of Bridges)
Prestressed concrete wire strand for cantilever construction of bridges, consisting of 7 wire, wire diameter of the cord (3mm , 4mm , 5mm ) , strand dia. (9.3mm , 12.5mm, 15.24mm)

PC Strands, Exported to Dubai

Material description Specification Type of wire PC STRAND 15.24mm ASTM A4 16/416M GRADE LR ASTMAD PC STRAND 12.50mm BS - STD GRADE LR 7PLY PC STRAND PC STRAND 9.53mm ASTM A416/416M GRADE LR LR 7PLY PC STRAND Super Gr

Pre-stressed Concrete Strand
Exported to Brazil.
Construction steel to produce concrete structures for buildings:
Diameter: 15.2 mm2
N/mm2
Area: 140 mm2
Metro Weight: GR / M
Strength: MPa
Break Load: 260.7 KN
Specification: 15.2 mm CP 190 RB /ASTM A-421 / ABNT NBR

Wire Strands
Exported to West Africa ( Ghana)
MPa Dia 4.9mm PC Steel Strands
3 x 2.25mm ( 3 wire )
3 x 3.00mm (3 wire )

Prestressing PC strand
Application: For Post-tesioning
Standard: PC strand 12.7 mm (0.5'') &#; ASTM 416
Wire strand exported to Vietnam

PC Strands, Low Relaxation, Grade 270K (Mpa), Left Hand Lay
PC strands exported to Philippines, with the following specifications:
Low relaxation PC strand
Relaxation value: Low
Quality: Grade 270K (Mpa), Left Hand Lay
Wire size: 12.7mm Diameter
Standards: According to ASTM A416 / A416M-02

PC Strand for the UK
PC STRAND 9.3mm
PC STRAND 12.5mm
Packing: In 2-3 tonnes COILS
Quality: A416-02

PC Stranded Wire
Material: Pc stranded wire for prestressed concrete
Specifications: quality as per astm-a416-
Very low relaxation to grade 270
Tensile strength: mpa
Coils weight: 2 &#; 2.5 tons
Packing: soft coils, water-proof paper inner, and p.p. cloth outer
Stranded wire exported to Lebanon

Pc Wire Strand
We supply PC wire strand to Korea, with quality as attached (single wire diameter 2.9mm; 1x3pc strand)
Wire samples tested in Korean Lab per standard KSD.

Inquiry please provide: Diameter of core strand, Number of wire, Tensile Strength, Quantity and Standard of strand. Welcome contact us for more details.

]

In most of the post-tensioned and pre-tensioned prestressed project, smooth steel strand is the most widely used prestressed steel. Stranded strand is mainly used to enhance the project, but also for nuclear power and the like works. Galvanized steel strand commonly used in the bridge of the tie rod, cable and external prestressing works. Epoxy coated steel stranded wire is similar to galvanized prestressed steel wire.

Standards

[

edit

]

Countries have standards for prestressed strand, such as: China Standard GB / T , American Standard ASTM A416, British standard BS and the Japanese standard JIS G, the Australian standard AS / NZS , Brazilian standard NBR-[2]

References

[

edit

]

Prestressed Concrete Steel Strand ( simplied as PC strand ) is a multi-wire steel cable helically wound by 2, 3, 7 or 19 high-strength steel mono wires. PC steel strand is widely used in slab post-tensioning, pre-stressing, mining, and stay cable applications.
We supply:
2 wire pc strand;
3 wire pc strand;
7 wire pc strand ( most popularly used);
19 wire pc strand.
We supply following Quality of Steel Strands for PC Concrete:
GB/T:1×7-9.5mm/11.1mm/12.7mm/15.2mm/15.7mm/17.8mm/21.6mm
ASTM416:1×7-7.9mm/9.53mm/11.11mm/12.7mm/13.2mm/14.29mm/15.24mm/17.8mm
BS :1×7-8.0mm/9.3mm/9.6mm/11.0mm/12.5mm/12.9mm/15.2mm/15.7mm
JIS G:1×7-12.7mm/15.2mm
UNE :1×7-9.3mm/13.0mm/15.2mm
AS/NZS: 9.5mm(7 wire)/12.7nn/15.2mm
Specifications can be customised according to customers / projects requirements.
How is Prestressing Strand Used:
Prestressing strand is fabricated into tentons, cages and guide channels (ducts) by strand pushing machine to be used in concrete constructions.

PRESTRESSED CONCRETE STRAND PRODUCTS

- EXPORT COUNTRIES AND QUALITIES

12.54 mm (0.6inch) prestressed concrete pc stranded wire for the tendons, supplied with anchors

PC Strand, low relaxation, left hand lay, plain.
Specification: ASTM A416-06
Size: 0.6"(15.24mm)
T/S: Mpa(min.)
Coil weight: 2.3MT(Min.)
Packing: 2 layers of water resistant materials and wrapped around each coil, 2 wooden dunnages underneath each coil.
Wire strand exported to Korea

Prestressed Concrete Strand (used in construction of Bridges)
Prestressed concrete wire strand for cantilever construction of bridges, consisting of 7 wire, wire diameter of the cord (3mm , 4mm , 5mm ) , strand dia. (9.3mm , 12.5mm, 15.24mm)

PC Strands, Exported to Dubai

Material description Specification Type of wire PC STRAND 15.24mm ASTM A4 16/416M GRADE LR ASTMAD PC STRAND 12.50mm BS - STD GRADE LR 7PLY PC STRAND PC STRAND 9.53mm ASTM A416/416M GRADE LR LR 7PLY PC STRAND Super Gr

Pre-stressed Concrete Strand
Exported to Brazil.
Construction steel to produce concrete structures for buildings:
Diameter: 15.2 mm2
N/mm2
Area: 140 mm2
Metro Weight: GR / M
Strength: MPa
Break Load: 260.7 KN
Specification: 15.2 mm CP 190 RB /ASTM A-421 / ABNT NBR

Wire Strands
Exported to West Africa ( Ghana)
MPa Dia 4.9mm PC Steel Strands
3 x 2.25mm ( 3 wire )
3 x 3.00mm (3 wire )

Prestressing PC strand
Application: For Post-tesioning
Standard: PC strand 12.7 mm (0.5'') &#; ASTM 416
Wire strand exported to Vietnam

PC Strands, Low Relaxation, Grade 270K (Mpa), Left Hand Lay
PC strands exported to Philippines, with the following specifications:
Low relaxation PC strand
Relaxation value: Low
Quality: Grade 270K (Mpa), Left Hand Lay
Wire size: 12.7mm Diameter
Standards: According to ASTM A416 / A416M-02

PC Strand for the UK
PC STRAND 9.3mm
PC STRAND 12.5mm
Packing: In 2-3 tonnes COILS
Quality: A416-02

PC Stranded Wire
Material: Pc stranded wire for prestressed concrete
Specifications: quality as per astm-a416-
Very low relaxation to grade 270
Tensile strength: mpa
Coils weight: 2 &#; 2.5 tons
Packing: soft coils, water-proof paper inner, and p.p. cloth outer
Stranded wire exported to Lebanon

Pc Wire Strand
We supply PC wire strand to Korea, with quality as attached (single wire diameter 2.9mm; 1x3pc strand)
Wire samples tested in Korean Lab per standard KSD.

Inquiry please provide: Diameter of core strand, Number of wire, Tensile Strength, Quantity and Standard of strand. Welcome contact us for more details.
